HP L1740 User Manual

B–4 User Guide
Technical Specifications
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used
modes and are set as factory defaults. This monitor automatically
recognizes these preset modes and they will appear properly sized
and centered on the screen.
Relative Humidity 20 to 80%
Power Source 100 - 240 VAC, 60-50 Hz
Power Consumption <70 watts typical
Input Terminals 15-pin D-type connector with cable included.
DVI-D connector with DVI-D cable not included
(available on select models)
L1940 Flat Panel Monitor (Continued)
Factory Preset Display Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 x 480 31.5 60.0
2640 x 480 37.9 73.0
3640 x 480 37.5 75.0
4 720 x 400 31.5 70.0
5 800 x 600 37.9 60.0
6 800 x 600 48.1 72.0
7 800 x 600 46.9 75.0
8 832 x 624 49.7 75.0

HP L1740 Specifications

General

3D	No
Response time	8 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Viewing angle, vertical	135 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	150 °
Digital vertical frequency	56 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1152 x 870, 1024 x 768 (XGA), 1360 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
USB hub version	2.0
DVI-I ports quantity	0
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (max)	60 W
Power consumption (average)	33 W
Power consumption (standby)	2 W
Power consumption (typical)	40 W
Product color	Black, White
Country of origin	China
Package weight	8800 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	248 mm
Height (with stand)	490 mm
Weight (with stand)	7000 g
Depth (without stand)	62 mm
Width (without stand)	371 mm
Height (without stand)	315 mm
Weight (without stand)	3760 g
