HP LP2275w User Manual

B Technical Specifications
NOTE: All performance specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component manufacturers' typical level
specifications for performance and actual performance may vary either higher or lower.
HP LP2275w Model
Table B-1 HP LP2275w Specifications
Display
Type
55.9 cm wide screen
TFT LCD
22 inches wide screen
Viewable Image Size 55.9 cm diagonal 22–inch diagonal
Tilt Adjustment -5 to 30°
Swivel Adjustment -45 to 45°
Height Adjustment 100 mm range 3.94–inch range
Pivot Clockwise
Maximum Weight (Unpacked) 8.12 kg 17.9 lbs.
Dimensions (include base)
Height (maximum)
Depth
Width
47.8 cm
25.3 cm
50.6 cm
18.8 inches
10.0 inches
19.9 inches
Maximum Graphic Resolution 1680 x 1050 (60 Hz) analog input
1680 x 1050 (60 Hz) digital input
Optimum Graphic Resolution 1680 x 1050 (60Hz) analog input
1680 x 1050 (60Hz) digital input
Text Mode 720 × 400
Dot Pitch 0.282 (H) × 0.282 (W) mm
Horizontal Frequency 30 to 93 kHz
Vertical Refresh Rate 48 to 85 Hz
Environmental Requirements Temperature
Operating Temperature
5 to 35° C 41 to 95° F
38 Appendix B Technical Specifications
Storage Temperature -20 to 60° C -4 to 140° F

HP LP2275w Specifications

General

3D	No
Panel type	PVA
Pixel pitch	0.282 x 0.282 mm
Response time	6 ms
Display diagonal	22 \
Display resolution	1680 x 1050 pixels
Display technology	LCD
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 93 kHz
Contrast ratio (typical)	1000:1
Display number of colors	-
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
Storage temperature (T-T)	20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	85 W
Power consumption (standby)	2 W
Power consumption (typical)	56 W
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	4
Product color	Black
Country of origin	China
Dimensions (W x D x H) (imperial)	19.9 x 10 x 18.8 \
Package weight	11300 g

Weight and Dimensions

Depth (with stand)	253 mm
Width (with stand)	506 mm
Height (with stand)	477 mm
Depth (without stand)	82.6 mm
Height (without stand)	328 mm
Weight (without stand)	8500 g
