Component Description
(2) SD Card Reader Supports the following optional digital card formats:
●
MultiMediaCard (MMC)
●
Secure Digital (SD) Memory Card
(3) USB port Connects an optional USB device.
(4) RJ-45 (network) jack Connects a network cable.
(5) Battery light
●
Amber: A battery is charging.
●
Blue: A battery is close to full charge capacity.
●
Blinking amber: A battery that is the only available power
source has reached a low battery level. When the battery
reaches a critical battery level, the battery light begins blinking
rapidly.
●
Off: If the computer is plugged into an external power source,
the light turns off when all batteries in the computer are fully
charged. If the computer is not plugged into an external power
source, the light stays off until the battery reaches a low
battery level.
(6) Power connector Connects an AC adapter.
(7) Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a deterrent, but
it may not prevent the computer from being mishandled or stolen.
Left-side components
Component Description
(1) External monitor port Connects an external VGA monitor or projector.
(2) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.
(3) Powered USB port Provides power to a USB device, such as an optional external
MultiBay or an optional external optical drive, if used with a
powered USB cable.
6 Chapter 1 Features
