RTC battery
Description Spare part number
RTC battery 914384-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 25).
5. Remove the battery (see Battery on page 30).
Remove the RTC battery:
1. Disconnect the battery cable from the system board (1).
2. Lift the Mylar from atop the battery (2).
3. Using a at tool, pry the battery out of the computer (3).
Reverse this procedure to install the RTC battery.
38 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
