6 Removal and replacement procedures for
Authorized Service Provider parts
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
CAUTION: This computer does not have user-replaceable parts. Only HP authorized service providers should
perform the removal and replacement procedures described here. Accessing the internal part could damage
the computer or void the warranty.
Component replacement procedures
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer. See Labels on page 14 for details.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
There are as many as 45 screws that must be removed, replaced, and/or loosened when servicing Authorized
Service Provider only parts. Make special note of each screw size and location during removal and
replacement.
Internal base plate
Description Spare part number
Internal base plate 821164-001
Before removing the internal base plate, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 25).
5. Remove the battery (see Battery on page 30).
6. Remove the keyboard (see Keyboard on page 39).
7. If equipped, disconnect the antenna cables from the WLAN module (see WLAN/Bluetooth combo card
on page 34).
8. If equipped, disconnect the antenna cables from the WWAN module (see WWAN module on page 36).
Remove the internal base plate:
42 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP mt43 Specifications

General

Form factor	Clamshell
Product type	Mobile thin client
Product color	Silver
Country of origin	China
Panel type	SVA
LED backlight	Yes
Display diagonal	14 \
Native aspect ratio	16:9
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor cache	2 MB
Processor cores	4
Processor model	PRO A8-9600B
Processor family	AMD PRO A8
Processor frequency	2.4 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	3.3 GHz
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
SSD form factor	M.2
Total storage capacity	128 GB
Compatible memory cards	SD
Number of SSDs installed	1
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R5
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Front camera signal format	720p
Battery capacity	51 Wh
Number of battery cells	3
AC adapter power	45 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit

Weight and Dimensions

Depth	226 mm
Width	338 mm
Height	18.9 mm
Weight	1480 g
