HP mt43 User Manual

USB/audio board
Description Spare part number
USB/audio board 914383-001
Before removing the USB/audio board, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 25).
5. Remove the battery (see Battery on page 30).
6. Remove the keyboard (see Keyboard on page 39).
7. Remove the internal base plate (see Internal base plate on page 42
Remove the USB/audio board:
1. Disconnect the cable from the system board (1).
2. Remove the 2 Phillips M2.5×5.0 screws (2) that secure the USB/audio board to the computer.
3. Lift up rear side of the board, and then pull it away from the side of computer to remove it (3).
Reverse this procedure to install the USB/audio board.
Component replacement procedures 49

HP mt43 Specifications

General

Form factor	Clamshell
Product type	Mobile thin client
Product color	Silver
Country of origin	China
Panel type	SVA
LED backlight	Yes
Display diagonal	14 \
Native aspect ratio	16:9
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor cache	2 MB
Processor cores	4
Processor model	PRO A8-9600B
Processor family	AMD PRO A8
Processor frequency	2.4 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	3.3 GHz
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
SSD form factor	M.2
Total storage capacity	128 GB
Compatible memory cards	SD
Number of SSDs installed	1
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R5
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Front camera signal format	720p
Battery capacity	51 Wh
Number of battery cells	3
AC adapter power	45 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Operating system installed	Windows 10 IoT Enterprise
Operating system architecture	64-bit

Weight and Dimensions

Depth	226 mm
Width	338 mm
Height	18.9 mm
Weight	1480 g
