Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
(2) Top cover with keyboard
For a detailed list of country codes, see Top cover with keyboard on page 60.
1 zone RGB lighting M57200-001
4 zone RGB lighting M57199-001
(3) Touchpad (does not include bracket)
NOTE: The touchpad cable is available using spare part number M57157-001.
M57156-001
(4) Speaker, right M57164-001
(5) Speaker, left M57165-001
(6) System board (includes processor; for use in models with discrete graphics memory)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows 10 operating system
AMD Ryzen 9 5900HX processor and NVIDIA GeForce RTX 3070MQ graphics M57232-xx1
AMD Ryzen 9 5900HX processor and AMD Radeon RX 6600M graphics M57193-xx1
AMD Ryzen 7 5800H processor and NVIDIA GeForce RTX 3070MQ graphics M57231-xx1
AMD Ryzen 7 5800H processor and AMD NVIDIA GeForce RTX 3050Ti graphics M57189-001
AMD Ryzen 7 5800H processor and NVIDIA GeForce RTX 3050 graphics M57187-xx1
AMD Ryzen 7 5800H processor and AMD Radeon RX 6600M graphics M57192-xx1
AMD Ryzen 5 5600H processor and NVIDIA GeForce RTX 3070MQ graphics M57230-xx1
AMD Ryzen 5 5600H processor and AMD Radeon RX 6600M graphics M57191-xx1
AMD Ryzen 5 5600H processor and AMD NVIDIA GeForce RTX 3050Ti graphics M57188-xx1
AMD Ryzen 5 5600H processor and NVIDIA GeForce RTX 3050 graphics M57185-xx1
AMD Ryzen 5 5600H processor and NVIDIA GeForce GTX 1650 graphics M57190-xx1
(7) Battery
6 cell, 83 Whr M41711-005
4 cell, 70 Whr M39179-005
(8) IR sensor board
NOTE: The IR sensor board cable is available as spare part number M57153-001.
M57152-001
(9) Card reader board
NOTE: The card reader board cable is available as spare part number M57155-001.
M57154-001
(10) Memory modules (DDR4-3200)
16 GB L67710-005
8 GB L46598-005
4 GB L83673-005
16 Chapter 3 Illustrated parts catalog
