Table 3-1 Computer major components and their descriptions (continued)
Item Component Spare part number
Intel Core i9-9880H processor and 8 GB of discrete graphics memory (GeForce GTX 2070) L57037-601
Intel Core i7-9750H processor and 8 GB of discrete graphics memory (GeForce GTX 2080) L57038-601
Intel Core i7-9750H processor and 8 GB of discrete graphics memory (GeForce GTX 2070) L57036-601
(15) Second display L57028-001
(16) Bottom cover (includes thermal pad) L57010-001
Cables
Table 3-2 Cables and their descriptions
Item Component Spare part number
(1) Power button board cable L57012-001
(2) IR sensor board cable L57013-001
(3) Touchpad cable L57014-001
(4) Display transfer board cable L65580-001
(5) Keyboard cable L57015-001
18 Chapter 3 Illustrated parts catalog
