Solid-state drive and Optane Memory Module
Table 5-2 Solid-state drive and Optane Memory Module descriptions and part numbers
Description Spare part number
2 TB L57033-001
1 TB L57031-001
512 GB + 32 GB Optane Memory L57035-001
512 GB L57034-001
256 GB L57032-001
Before removing the solid-state drive, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover on page 27).
3. Disconnect the battery (see Battery and speakers on page 32).
Remove the solid-state drive:
▲ Remove the Phillips M2.0 × 2.0 screw (1), and then pull the drive from the socket (2).
Reverse this procedure to install the solid-state drive.
Component replacement procedures 29
