Removal and Replacement Procedures
Maintenance and Service Guide 5–29
5.13 Keyboard
1. Prepare the computer for disassembly (Section 5.3) and then
remove the following components:
a. Memory/Mini PCI module compartment cover
(Section 5.6)
b. Switch cover (Section 5.10)
c. Keyboard assembly frame (Section 5.11)
2. Turn the keyboard assembly frame upside down with the
LED board toward you.
Keyboard Spare Part Number Information
For use in:
France
French Canada
Germany
Italy
Norway
403809-051
403809-121
403809-041
403809-061
403809-091
Spain
Sweden and Finland
United Kingdom
United States
403809-071
403809-101
403809-031
403809-001
