5–50 Maintenance and Service Guide

Removal and Replacement Procedures

5.16 System Board

✎

When replacing the system board, ensure that the following

components are removed from the defective system board and

installed on the replacement system board:

■ Memory modules (Section 5.6)

■ Mini PCI communications module (Section 5.7)

■ RTC battery (Section 5.8)

■ Speaker (Section 5.20)

■ Heat sink (Section 5.21)

■ Processor (Section 5.22)

■ Fan assembly (Section 5.23)

■ PC Card assembly (Section 5.24)

1. Prepare the computer for disassembly (Section 5.3),

and then remove the following components:

a. Hard drive (Section 5.4)

b. Memory/Mini PCI module compartment cover

(Section 5.6)

c. Optical drive (Section 5.9)

d. Switch cover (Section 5.10)

e. Keyboard assembly frame (Section 5.11)

f. Display assembly (Section 5.14)

g. Top cover (Section 5.15)

System Board Spare Part Number Information

For use with HP Pavilion dv8200 models

For use with HP Pavilion dv8000 movels

417029-001

403790-001
