Item Component Spare part number
(12) System board
System board equipped with Qualcomm Snapdragon APQ8074 Quad core 2.3GHz
Graphics Chipset, 2GB RAM memory, and 16 GB eMMC hard drive
793497-001
System board equipped with Qualcomm Snapdragon APQ8074 Quad core 2.3GHz
Graphics Chipset, 2GB RAM memory, and 32 GB eMMC hard drive
793498-001
System board equipped with Qualcomm Snapdragon APQ8074 Quad core 2.3GHz
Graphics Chipset, 2 GB RAM memory, and 16 GB eMMC hard drive for models with WWAN
capability
800051-001
System board equipped with Qualcomm Snapdragon APQ8074 Quad core 2.3GHz
Graphics Chipset, 2 GB RAM memory, and 32 GB eMMC hard drive for models with WWAN
capability
800052-001
(13) Audio jack 793489-001
(14) Audio cable 793489-001
(15) Speaker Kit, bottom speaker (includes cable) 793495-001
(16) 7.8 in, LED, TouchScreen, display panel assembly 793492-001
Miscellaneous parts
Component Spare part number
10W, 2.0 type-b USB adapter with Micro USB cable 793486-001-001
10W, 2.0 type-b USB adapter with Micro USB cable and localized cable plug support
For use only in Latin America 798685-001
For use only in Australia 798685-002
For use only in the United Kingdom 798685-003
For use only in India 798685-005
For use only in the People’s Republic of China 798685-006
For use only in North America 798685-008
For use only in Europe 798685-009
For use only in Brazil 795552-012
For use only in S. Korea 798685-014
18W POGO adapter
For use only in Latin America 795552-001
For use only in Australia 795552-002
For use only in the United Kingdom 795552-003
For use only in India 795552-005
For use only in the People’s Republic of China 795552-006
For use only in North America 795552-008
Miscellaneous parts 5
