2. Disconnect the battery cable from the system board, and then remove the battery (2).
NOTE: Be careful not to bend the battery as you lift it.
Reverse this procedure to install the battery.
Rear-facing webcamera
Description Spare part number
Rear-facing webcamera (includes cable) 793500-001
Before removing the rear-facing webcamera, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off, turn the tablet on, and then shut it down
through the operating system.
2. Disconnect the power from the tablet by unplugging the power adapter cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 14).
5. Remove the battery (see
Battery on page 15).
Remove the rear-facing webcamera:
1. Remove the tape(1), and then release the ZIF connector (2) that secures the rear-facing webcamera to
the system board.
16 Chapter 6 Removal and replacement procedures
