HP Pro x2 612 G2 User Manual

Volume button
Description
Volume button (included with the Plastics Kit) 918392-001
IMPORTANT: Make special note of each screw size and location during removal and replacement.
Before removing the volume button, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Keyboard (select products only) (see Keyboard (select products only) on page 31)
b. Micro SIM card tray (see Micro SIM card tray on page 32)
c. MicroSD card tray (see MicroSD memory card tray on page 33)
d. Rear cover (see Rear cover on page 34)
e. Disconnect the battery (see Disconnecting the battery on page 35)
f. Kickstand (see Kickstand on page 36)
g. SSD (see SSD on page 38)
h. Display panel (see Display panel on page 45)
i. Battery (see Battery on page 49)
j. System board (see System board on page 55)
k. Smart card reader board (see Smart card reader board and bracket on page 61)
Remove the volume button:
▲
Push the button in to remove it from the frame.
64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pro x2 612 G2 Specifications

General

Operating system architecture	64-bit
HD type	WUXGA+
Display diagonal	12 \
Display resolution	1920 x 1280 pixels
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	LPDDR3-SDRAM
Maximum internal memory	- GB
Optical drive type	No
Compatible memory cards	MicroSD (TransFlash)
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	Serial ATA
SSD form factor	M.2
Storage media type	SSD
Total storage capacity	128 GB
Graphics card	HD Graphics 615
Graphics card manufacturer	Intel
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 615
Chassis type	Tablet
Product color	Black
Processor cache	2 MB
Processor cores	2
Processor family	Intel® Pentium®
Processor frequency	1.5 GHz
Antenna type	2x2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
WLAN controller model	Intel Dual Band Wireless-AC 8265
Sustainability certificates	ENERGY STAR
Rear camera HD type	HD
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
Battery capacity	41.58 Wh
Number of battery cells	4

Weight and Dimensions

Depth	91 mm
Width	300 mm
Height	213.8 mm
Weight	850 g
