HP Proliant DL580 User Manual

Server specifications 123
Specification Value
BTUs per hour @100 VAC–3960 BTU
@200 VAC–5450 BTU
Power supply output —
Power supply output 910 W (low line)
1300 W (high line)

HP Proliant DL580 Specifications

General

Product Line	ProLiant
Server Type	Rack Server
Form Factor	4U
CPU Socket Type	LGA 3647
Memory	Up to 6 TB
Processor	Intel Xeon
Memory Type	DDR4
Storage Controller	Smart Array
Network	FlexibleLOM
Power Supply	Redundant Power Supplies
Management	iLO (Integrated Lights-Out)

Summary

Server Component Identification

Front Panel Components and Controls

Covers the identification and function of front panel components, including buttons, LEDs, and connectors.

Rear Panel Components and Indicators

Details the components and status LEDs found on the server's rear panel for connectivity and diagnostics.

Internal Component Locations

Identifies key internal components like system boards, fans, and switches, crucial for understanding server layout.

Drive and Memory Indicators

Explains the LEDs for Systems Insight Display, DIMM slots, and hard drives, aiding in status monitoring and troubleshooting.

Server Operations

Server Power Management

Instructions for powering the server on and off, including standby modes and safety precautions.

Rack Mounting Procedures

Guidance on extending the server from its rack for servicing and safe removal or reinstallation.

Component Access and Replacement

Procedures for accessing internal components by removing the access panel, system cage, and replacing hot-plug fans.

System Status Monitoring

Information on accessing the Systems Insight Display to monitor server health and status.

Server Setup

Installation Services and Planning

Information on optional HP installation services, rack planning, and optimum environmental conditions.

Physical Installation Requirements

Covers space, airflow, temperature, power, and electrical grounding requirements for server installation.

Rack Safety and Handling

Important warnings and cautions related to rack stability, component handling, and safe installation practices.

Initial Server Configuration

Steps for powering up, configuring the server, installing the operating system, and registering the system.

Hardware Options Installation

Introduction and Processor Options

General advice for hardware installation and detailed information on processor options and module removal.

Installing Processors and Drives

Step-by-step guides for installing processors, SAS/SATA drives, and redundant power supplies.

Cache and Media Drive Installation

Procedures for installing battery-backed write cache and optional media drives like DVD or diskette drives.

Expansion Board Options

Expansion Slot Overview and Mezzanine Options

Describes server expansion slots and the installation of PCI-X and PCI Express mezzanine options.

Installing PCI Express Bus Expanders and Boards

Guides for installing PCI Express bus expanders and non-hot-plug expansion boards into available slots.

Installing Hot-Plug Expansion Boards

Procedures for installing hot-plug expansion boards, including PCI-X Hot Plug options, without system interruption.

Memory Options

Memory Overview and Configuration

Introduces memory capabilities, types (Advanced ECC, Online Spare, Mirrored, RAID), and general configuration rules.

DIMM Slot Identification and Types

Explains DIMM slot locations, bank assignments, and the difference between single- and dual-rank DIMMs.

Memory Installation and Replacement

Procedures for removing/installing memory board blanks, and installing/replacing memory boards while the server is running or powered off.

Memory Configuration and Testing

Guides on configuring memory modes (AMP) using RBSU and performing memory tests.

Server Cabling

Cabling Guidelines and Procedures

General guidelines for cabling storage devices, mezzanine boards, BBWC, and hard drives, with safety precautions.

Front Panel Cabling

Details the connections for front panel USB and power switch cables to the server's internal components.

Server Software and Configuration Utilities

Configuration and Deployment Tools

Overview of tools like SmartStart and RDP for server setup, configuration, and automated deployment.

System Setup and Management Utilities

Explanation of RBSU for system configuration, auto-configuration process, and management tools.

Diagnostic and Support Utilities

Information on diagnostic tools (Insight Diagnostics, Survey Utility) and remote support utilities (ISEE) for system analysis and maintenance.

System Maintenance and Updates

Guidance on keeping the system current with drivers, support packs, and operating system updates.

Electrostatic Discharge (ESD) Prevention

ESD Prevention Measures

Precautions to avoid system damage from static electricity, including handling and storage guidelines.

Grounding Methods for ESD Safety

Describes various grounding techniques and tools, such as wrist straps, to safely handle sensitive electronic parts.

Troubleshooting Server Issues

Troubleshooting Resources and Preparation

Lists resources for troubleshooting, pre-diagnostic steps, safety information, and symptom gathering.

Diagnostic Procedures and Flowcharts

Introduces troubleshooting flowcharts for various issues like power-on, POST, OS boot, and general fault indications.

Specific Problem Flowcharts

Detailed flowcharts for diagnosing power-on, POST, OS boot, and server fault indication problems.

Error Message Interpretation

Explains POST error messages and beep codes, plus specific processor-related error messages and their causes.

Regulatory Compliance Notices

FCC and General Compliance Information

Details FCC regulations, rating labels, and general compliance statements for electronic devices.

Regional Compliance Statements

Provides compliance notices for Canada, the European Union, Japan, and Korea, along with modification warnings.

Specific Product Compliance

Covers laser safety compliance for optical devices and important notices regarding battery replacement and disposal.

Server Specifications

Environmental Specifications

Lists the operating temperature, humidity, and altitude derating requirements for optimal server performance.

Physical and Electrical Specifications

Details the server's dimensions, weight, input voltage, frequency, current, power, and BTU ratings.

Technical Support and Customer Service

Contacting HP Support

Information on what details to provide before contacting HP and how to reach technical support.

Customer Self Repair (CSR) Program

Explains HP's CSR program for replacing defective parts, including categories, procedures, and contact information.

Acronyms and Abbreviations

Common Server Technology Acronyms

Defines key acronyms related to server hardware, memory, and networking technologies.

Key Industry and Process Acronyms

Lists acronyms for standards organizations, utilities, and management protocols used in server management.

Storage and Configuration Acronyms

Defines acronyms related to storage technologies (RAID, SCSI), configuration utilities (RBSU, ORCA), and data protocols.

Interface and System Acronyms

Explains acronyms for interfaces (USB, PCI), system components (PPM, SIM), and data types (SDRAM, DRAM).
