HP Proliant DL580 User Manual

Server component identification 16
Item Description Item Description
7 Connectors for one of the
following:
• PCI-X Hot Plug
mezzanine option
• PCI Express x4
mezzanine option
• PCI Express x8
mezzanine option
16 Boot device selector switch
(default = FLP TOP)
8 Battery packs and connectors
for BBWC (optional)
17 Systems Insight Display
9 PCI-X non-hot-plug expansion
slot 3, 64-bit/133-MHz
— —
System maintenance switch
The system maintenance switch (SW1) is an eight-position switch that is used for system configuration. The
default position for all eight positions is Off.
Position Description Function
S1 iLO 2 Security Off = iLO 2 security is enabled
On = iLO 2 security is disabled
S2 Configuration
lock
Off = System configuration can
be changed
On = System configuration is
locked
S3 Reserved Reserved
S4 Reserved Reserved
S5 Password
protection
override
Off = No function
On = Clears power-on
password and administrator
password
S6 Invalidate
configuration
Off = Normal
On = Clears NVRAM
S7 Reserved Reserved
S8 Reserved Reserved
Boot device selector switch
The boot device selector switch setting determines the device access order of the multibay drives in the
server. The default setting for the boot device selector switch is FLP TOP.
