Component identification 76
Fan locations
Item Description
1
Rear system fan (fan 1, for processor cooling)
2
Front system fan (fan 2, for expansion board cooling)
T-10/T-15 Torx screwdriver
The server includes a T-10/T-15 Torx screwdriver located on the side of the media drive cage. Use the
screwdriver to loosen screws during hardware configuration procedures.
