Cabling 81
Item Description
2
Mini-SAS cable
3
Mini-SAS cable
Media drive cabling
• Media drives in a nonredundant power configuration
Item Description
1
Upper media drive power cable
2
Lower media drive SATA cable
3
Upper media drive SATA cable
4
Lower media drive power cable
