HP s500 User Manual

17
Video Mode Screen Layout
Standby layout Recording Layout
No. Item Description
1 Record Mode Indicates the current mode.
2 Zoom indicator Displays zoom.
3 Time remaining Indicates the remaining time of video available.
4 Battery Indicates battery level.
5 Storage media Indicates current storage media in use.
6 Display focus area settings Use to frame subject to record.
7 Macro Indicates macro is enabled.
8 White balance Displays white balance settings.
9 Metering Displays metering settings.
10 Resolution Displays movie resolution settings.
11 Key indicator Indicates the buttons to press on the camera to apply the functions.
12 Recorded time Displays recorded time.
13 Recording status Indicates recording status.
14 Pre-record
Indicates pre-record is enable.
The Pre-Record icon appears on the screen in red color as the same position as zoom indicator.

HP s500 Specifications

General

HP segment	Home
Certification	WEEE; EU RoHS; RoHS Ukraine; RoHS Turkey; REACH; EPEAT Bronze; OSHA; CE
Product color	-
Sound pressure level (printing)	73 dB
USB port	No
Ethernet LAN	Yes
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Printing colors	Black, Cyan, Magenta, Yellow
Print technology	Dye-sublimation
Maximum resolution	1200 x 1200 DPI
Number of print cartridges	4
Maximum print size	1625 x 1220 mm
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	1053 mm
Package width	2750 mm
Package height	1696 mm
Package weight	355000 g
Power consumption (standby)	80 W
Power consumption (typical)	1000 W

Weight and Dimensions

Depth	710 mm
Width	2560 mm
Height	1420 mm
Weight	226000 g
