3. At the DriveLock Password prompt, type the current DriveLock user password or master password that
you are changing, press enter, and then press or tap f10 to enter Computer Setup.
4. Select Security, select Hard Drive Utilities, select DriveLock/Automatic DriveLock, and then press
enter.
5. Select the hard drive you want to manage, and then press enter.
6. Make the selection for the DriveLock password that you want to change, and then follow the on-screen
instructions to enter passwords.
NOTE: The Change DriveLock Master Password option is visible only if the DriveLock master password
was provided at the DriveLock Password prompt in step 3.
7. To exit Computer Setup, select Main, select Save Changes and Exit, and then follow the on-screen
instructions.
Using Windows Hello (select products only)
On products equipped with a ngerprint reader or an infrared camera, you can use Windows Hello to sign in by
swiping your nger or looking at the camera.
To set up Windows Hello, follow these steps:
1. Select the Start button, select Settings, select Accounts, and then select Sign-in options.
2. Under Windows Hello, follow the on-screen instructions to add both a password and a numeric PIN, and
then enroll your ngerprint or facial ID.
NOTE: The PIN is not limited in length, but it must consist of numbers only. No alphabetic or special
characters are allowed.
Using antivirus software
When you use the computer to access e-mail, a network, or the Internet, you potentially expose it to
computer viruses. Computer viruses can disable the operating system, programs, or utilities, or cause them to
function abnormally.
Antivirus software can detect most viruses, destroy them, and, in most cases, repair any damage they have
caused. To provide ongoing protection against newly discovered viruses, antivirus software must be kept up
to date.
Windows Defender is preinstalled on your computer. It is strongly recommended that you continue to use an
antivirus program in order to fully protect your computer.
For more information about computer viruses, access the HP Support Assistant.
Using rewall software
Firewalls are designed to prevent unauthorized access to a system or network. A rewall can be a software
program you install on your computer and/or network, or it can be a solution made up of both hardware and
software.
There are two types of rewalls to consider:
Host-based rewalls—Software that protects only the computer it is installed on.
Network-based rewalls—Installed between your DSL or cable modem and your home network to
protect all the computers on the network.
26 Chapter 5 Security

Table of Contents

Other manuals for HP Sprout

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Sprout and is the answer not in the manual?

HP Sprout Specifications

General IconGeneral
Full HDYes
Screen shapeFlat
Display diagonal23 \
Touch technologyMulti-touch
Native aspect ratio16:9
Detachable displayNo
Storage drive interfaceSerial ATA
Tcase71.35 °C
Bus typeDMI
SteppingC0
Processor codeSR1QM
Processor cache8 MB
Processor cores4
Processor modeli7-4790S
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Number of QPI links0
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency4 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)65 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2
Internal memory8 GB
Memory slots typeSO-DIMM
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)2 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHybrid-HDD
Hybrid-HDD cache typeFlash
Total storage capacity1000 GB
Compatible memory cardsSD, SDHC, SDXC
Number of storage drives installed1
On-board graphics card ID0x412
Discrete graphics card modelNVIDIA® GeForce® GT 745A
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2048 GB
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.7 GB
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.1
On-board graphics card dynamic frequency (max)1200 MHz
Number of displays supported (on-board graphics)3
Audio systemDTS Studio Sound
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating system installedWindows 8.1
Scalability1S
Processor ARK ID80808
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2013C
Intel® Smart Response Technology-
Intel Identity Protection Technology version1.00
Product colorSilver
Country of originChina
Product typeAll-in-One PC
Motherboard chipsetIntel® H97
Total megapixels1 MP
AC adapter power350 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)577 mm
Width (with stand)594 mm
Height (with stand)605 mm
Weight (with stand)15280 g
