Page #42 background imageLoading...
Page #42 background image
You can use Windows tools to create system restore points and create backups of personal information,
see Using Windows tools on page 36.
If your computer does list the Recovery partition and the Windows partition, you can use HP Recovery
Manager to create recovery media after you successfully set up the computer. HP Recovery media can be
used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the
original operating system and software programs that were installed at the factory and then congures
the settings for the programs. HP Recovery media can also be used to customize the system or restore
the factory image if you replace the hard drive.
Only one set of recovery media can be created. Handle these recovery tools carefully, and keep
them in a safe place.
HP Recovery Manager examines the computer and determines the required storage capacity for
the media that will be required.
To create recovery discs, your computer must have an optical drive with DVD writer capability, and
you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use
rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray)
discs; they are not compatible with HP Recovery Manager software. Or, instead, you can use a high-
quality blank USB ash drive.
If your computer does not include an integrated optical drive with DVD writer capability, but you
would like to create DVD recovery media, you can use an external optical drive (purchased
separately) to create recovery discs. If you use an external optical drive, it must be connected
directly to a USB port on the computer; the drive cannot be connected to a USB port on an external
device, such as a USB hub. If you cannot create DVD media yourself, you can obtain recovery discs
for your computer from HP. See the Worldwide Telephone Numbers booklet included with the
computer. You can also nd contact information on the HP website. Go to http://www.hp.com/
support, select your country or region, and follow the on-screen instructions.
Be sure that the computer is connected to AC power before you begin creating the recovery media.
The creation process can take an hour or more. Do not interrupt the creation process.
If necessary, you can exit the program before you have nished creating all of the recovery DVDs.
HP Recovery Manager will nish burning the current DVD. The next time you start HP Recovery
Manager, you will be prompted to continue.
To create HP Recovery media:
IMPORTANT: For a tablet with a detachable keyboard, connect the keyboard to the keyboard dock before
beginning these steps.
1. Type recovery in the taskbar search box, and then select HP Recovery Manager.
2. Select Create recovery media, and then follow the on-screen instructions.
If you ever need to recover the system, see Recovering using HP Recovery Manager on page 37.
Using Windows tools
You can create recovery media, system restore points, and backups of personal information using Windows
tools.
NOTE: If storage is 32 GB or less, Microsoft System Restore is disabled by default.
For more information and steps, see the Get started app.
Select the Start button, and then select the Get started app.
36 Chapter 8 Backing up, restoring, and recovering

Table of Contents

Other manuals for HP Sprout

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Sprout and is the answer not in the manual?

HP Sprout Specifications

General IconGeneral
Full HDYes
Screen shapeFlat
Display diagonal23 \
Touch technologyMulti-touch
Native aspect ratio16:9
Detachable displayNo
Storage drive interfaceSerial ATA
Tcase71.35 °C
Bus typeDMI
SteppingC0
Processor codeSR1QM
Processor cache8 MB
Processor cores4
Processor modeli7-4790S
System bus rate5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-4700 Desktop series
Processor socketLGA 1150 (Socket H3)
Processor threads8
Processor codenameHaswell
Number of QPI links0
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency4 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)65 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
Memory slots2
Internal memory8 GB
Memory slots typeSO-DIMM
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)2 x 4 GB
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHybrid-HDD
Hybrid-HDD cache typeFlash
Total storage capacity1000 GB
Compatible memory cardsSD, SDHC, SDXC
Number of storage drives installed1
On-board graphics card ID0x412
Discrete graphics card modelNVIDIA® GeForce® GT 745A
On-board graphics card modelIntel® HD Graphics 4600
Discrete graphics card memory2048 GB
Discrete graphics memory typeGDDR3
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.7 GB
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version11.1
On-board graphics card dynamic frequency (max)1200 MHz
Number of displays supported (on-board graphics)3
Audio systemDTS Studio Sound
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating system installedWindows 8.1
Scalability1S
Processor ARK ID80808
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Thermal solution specificationPCG 2013C
Intel® Smart Response Technology-
Intel Identity Protection Technology version1.00
Product colorSilver
Country of originChina
Product typeAll-in-One PC
Motherboard chipsetIntel® H97
Total megapixels1 MP
AC adapter power350 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)577 mm
Width (with stand)594 mm
Height (with stand)605 mm
Weight (with stand)15280 g
