HP TOUCHSMART TM2 User Manual

media controls, keys 33
MediaSmart
using 36
MediaSmart software 36
memory module
inserting 64
removing 64
memory module compartment
cover
removing 63
replacing 65
memory module compartment,
identifying 14
memory test 80
microphone (audio-in) jack,
identifying 12
Microsoft Certificate of Authenticity
label 85
minimizing interference 91
monitor, connecting 40
mouse, external
setting preferences 26
multimedia software
installing 37
using 36
mute key
identifying 33
using 37
mute light, identifying 9
N
network cable, connecting 25
network icon 16, 90
network key 90
network security codes
network key 90
SSID 90
O
operating environment 83
operating system
Microsoft Certificate of
Authenticity label 85
Product Key 85
optical drive
external 37
sharing 37, 61
optical drive, external 60
P
page down hotkey 34
page up hotkey 34
passwords
administrator 68
power-on 68
set in Setup Utility 67
set in Windows 67
pen
identifying 28
storing 28
using 28
pen holder 28
pen holder, identifying 13
pen tether eyelet 28
pinching TouchPad gesture 27,
31
pointing devices
setting preferences 26
ports
external monitor 40
HDMI 12, 40
USB 12, 53
power
connecting 51
conserving 44
power connector, identifying 12
power light, identifying 11
power switch, identifying 11
power-on password
creating 69
entering 69
managing 69
primary hard disk self test 80
Product Key 85
product name and number,
computer 85
programs, using 36
projector, connecting 40
Q
quick troubleshooting 87
R
readable media 43
recovering a program or driver 73
recovering from the dedicated
recovery partition 76
recovering from the recovery
discs 76
recovery discs 73
recovery discs, creating 4
Recovery Manager 73, 76
recovery partition 73
recovery, system 76
regulatory information
regulatory label 85
wireless certification labels 86
restore points 75
rotate button, identifying 11
rotating TouchPad gesture 27,
30
routine care 84
S
screen brightness keys 33
screen image, switching 33
scrolling TouchPad gesture 26,
30
security cable slot, identifying 13
security cable, installing 70
Security menu 79
security, wireless 21
serial number, computer 85
service tag 85
setup of WLAN 19
Setup Utility
changing the language 77
displaying system
information 78
exiting 79
menus 79
navigating 78
passwords set in 67
restoring default settings 78
selecting 78
starting 77
shared drives 61
shutdown 42
SIM
inserting 22
removing 23
Sleep
exiting 43
initiating 43
slots
Digital Media 12
memory 63
security cable 13
software
Disk Cleanup 56
Disk Defragmenter 55
94 Index
Antenna House XSL Formatter (Evaluation) http://www.antennahouse.com/

HP TOUCHSMART TM2 Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-300 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	1.33 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	18 W
CPU multiplier (bus/core ratio)	10
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
Internal memory	3 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 + 1 x 2 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, xD
Number of HDDs installed	1
Display diagonal	12.1 \
Touch technology	Multi-touch
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	41 - 95 °F
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	166 MHz
On-board graphics card dynamic frequency (max)	500 MHz
Audio system	Dolby Advanced
Speakers manufacturer	Altec Lansing
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit LAN, WLAN
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Keyboard layout	-
Pointing device	Clickpad
Operating system installed	Windows 7 Home Premium
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Country of origin	China
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Cable lock slot type	Kensington
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Processor code	SLBSL
Processor ARK ID	50028
Processor package size	BGA 34 x 28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2

Weight and Dimensions

Depth	326 mm
Width	230 mm
Weight	1893 g
Height (rear)	30 mm
Height (front)	24.3 mm
