HP ZBook 14 G2 Mobile Workstation User Manual

Reverse this procedure to install the fingerprint reader board.
System board
NOTE: The system board spare part kit includes replacement thermal material.
Description Spare part number
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and the Windows 8
Professional operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799543-601
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and the Windows 8
Standard operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799543-501
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and a non-
Windows 8 operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799543-001
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem with discrete memory,
and the Windows 8 Professional operating system for use only on HP ZBook 14 G2 Mobile Workstation
computer models
802792-601
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem with discrete memory,
and the Windows 8 Standard operating system for use only on HP ZBook 14 G2 Mobile Workstation
computer models
802792-501
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem with discrete memory, and a
non-Windows 8 operating system for use only on HP ZBook 14 G2 Mobile Workstation computer models
802792-001
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), Intel HD Graphics 5500 graphics subsystem with UMA memory, and the Windows 8
Professional operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799513-601
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), Intel HD Graphics 5500 graphics subsystem with UMA memory, and the Windows 8
Standard operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799513-501
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), Intel HD Graphics 5500 graphics subsystem with UMA memory, and a non-Windows 8
operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799513-001
Equipped with an Intel Core i7-5500U 2.40-GHz (SC turbo up to 3.00-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and the Windows 8
Professional operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799517-601
Equipped with an Intel Core i7-5500U 2.40-GHz (SC turbo up to 3.00-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and the Windows 8
Standard operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799517-501
Equipped with an Intel Core i7-5500U 2.40-GHz (SC turbo up to 3.00-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete memory, and a non-
Windows 8 operating system for use only on HP EliteBook 840 G2 Notebook PC computer models
799517-001
Equipped with an Intel Core i7-5500U 2.40-GHz (SC turbo up to 3.00-GHz) processor (4.0-MB L3 cache,
dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem with discrete memory,
and the Windows 8 Professional operating system for use only on HP ZBook 14 G2 Mobile Workstation
computer models
802791-601
ENWW Component replacement procedures 91
