Table 3-40 Signaling specifications of the LMPT
Board Signaling Specification (CAPS)
LMPT 30
The following table lists the maximum number of UEs in RRC_Connected mode supported by
the LMPT.
Table 3-41 Maximum number of UEs in RRC_Connected mode
Board Maximum Number of UEs in
RRC_Connected Mode
LMPT 5400
The maximum of data radio bearers (DRBs) supported by the LMPT is three times the maximum
number of UEs in RRC_Connected mode.
NOTE
For the signaling specifications of an entire eNodeB, see section "Signaling Specifications" in 3900 Series
Base Station Technical Description. For the maximum number of DRBs and UEs in RRC_Connected
mode, see section "Baseband Specifications" in 3900 Series Base Station Technical Description.
Panel
Figure 3-26 shows the LMPT.
Figure 3-26 LMPT
Functions
The LMPT performs the following functions:
l Enables configuration management, device management, performance monitoring,
signaling processing, and radio source management
l Controls all boards in the system
l Provides the system clock
l Enables signal exchange between the eNodeB and MME/S-GW
BTS3900C (Ver.C)
Hardware Description 3 BTS3900C Modules
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
58
