FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
300 mm air conditioner
adaptive frame
Adapt to 1200 mm
or 1100 mm deep
cabinets. When
there is an odd
number of 300 mm
air conditioners, use
the adaptive frame
to supplement the
opposite position to
ensure that the two
rows of cabinets
have the same
length.
3.1.9 (Optional) Base
Adjustable Bases
The widths of adjustable bases for a Smart Module include 300 mm, 600 mm, and 800 mm.
The minimum adjustment range is 1 mm.
Table 3-5 lists base specifications.
Table 3-5 Base specifications
Width: 600 mm; height: 270 mm
≤ H ≤ 410 mm (adjustable);
depth: 1000 mm, 1100 mm, or
1200 mm (adjustable)
Used to support an IT cabinet,
network cabinet, battery cabinet, and
PDC that are all 600 mm wide.
Width: 600 mm; height
(adjustable): 410 mm ≤ H ≤ 700
mm; depth (adjustable): 1000
mm, 1100 mm, or 1200 mm
Width: 300 mm; height: 270 mm
≤ H ≤ 410 mm (adjustable);
depth: 1000 mm, 1100 mm, or
1200 mm (adjustable)
Used to support a 300 mm wide air
conditioner.
Width: 300 mm; height: 410 mm
≤ H ≤ 700 mm (adjustable);
depth: 1000 mm, 1100 mm, or
1200 mm (adjustable)
