Configuring the DSL uplink
By configuring the DSL uplink, you can choose any of the following methods to surf
the Internet:
z
Using the Embedded PPP Dial-Up Software on the HG655d
z
Using the PPP Dial-Up Software on Your Computer
Using the Embedded PPP Dial-Up Software on the HG655d
If you select this method for accessing the network, the HG655d starts to set up a
dial-up connection automatically after the startup. You can access the network after you
power on your computer.
To configure the HG655d and your computer for the network access, do as follows:
Step 1
Step 2
Log in to the web page.
Configure the PTM PVC and ATM PVC.
1. In the navigation tree, choose Basic > ATM.
2. Click New.
3. Enter VPI and VCI in the VPI/VCI text box provided by the Internet
Service Provider.
4. Select EoA from the DSL link type option button, and keep the default
settings of other parameters.
5. Click Submit.
Just keep the default settings for PTM settings.
Step 3
Enable the embedded dial-up function.
1. In the navigation tree on the left of the web page, choose Basic > WAN.
2. Click New.
3. Select a PVC from the Layer2 interface drop-down combo box.
z The HG655d supports ADSL/VDSL compliance uplink.
z When choose the ADSL uplink mode, the name of PVC should be
composed by the value of VPI and VCI. When choose the VDSL
uplink mode, the name of PVC should begin with ptm.
4. Select Enable check box for WAN connection.
5. Select VOICE_TR069_INTERNET from the Service list drop-down
combo box.
6. Select Route from the Connection mode drop-down combo box.
7. Select PPPoE option button for Connection type.
8. Select Enable check box for NAT.
4
