4
Indicator Status Description
Blinking The HG659b is working in routing
mode.
The WAN connection is set up.
Data is being transmitted.
Off The HG659b is working in bridge
mode.
The HG659b is working in routing
mode, but the connection to the WAN
has not been set up.
The HG659b is powered off.
WLAN Steady
on
The HG659b has WLAN enabled, but is
not transmitting data.
Fast
Blinking
(2Hz)
The HG659b has WLAN enabled, and
data is being transmitted.
Slow
Flashing
(1Hz)
The HG659b is attempting to connect to
a wireless client over the WLAN using
the WPS function.
This process lasts for no longer than 120
seconds.
Off The WLAN function is disabled.
The HG659b is powered off.
VoIP Steady
on
The HG659b is registered with a SIP
server, but no data is being transmitted.
Blinking The HG659b is registered with a SIP
server, and data is being transmitted.
Off The HG659b is not registered with a
SIP server.
The HG659b is powered off.
