Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
1004
Item
Specification
Environment standard
RoHS
Security standard
FCC class B, IEC 60825-1 Class 1
ESD(HBM1) (V)
500
Transmission rate (bit/s)
41.25G
Connector type
LC
Transmission distance (km)
40
Optical fiber type
SMF
Center wavelength (nm)
1271
1291
1311
1331
Working wavelength range of the optical
transmitter (nm)
1264.5-1277.5
1284.5-1297.5
1304.5-1317.5
1324.5-1337.5
Maximum sending optical power (AVG)
(dBm)
-
Maximum sending optical power (OMA)
(dBm)
per lane:5
Minimum sending optical power (AVG)
(dBm)
-
Minimum sending optical power (OMA)
(dBm)
per lane:0.3
Working wavelength range of the optical
receiver (nm)
1264.5-1277.5
1284.5-1297.5
1304.5-1317.5
1324.5-1337.5
Receiving sensitivity (AVG) (dBm)
-
Receiving sensitivity (OMA) (dBm)
per lane:-19
Saturated optical power (dBm)
per lane:-4
Minimum extinction ratio (dB)
5.5
