NE40E
Hardware Description
1
Hardware Description
Issue
01
(
2018
-
05
-
03
)
163
Fi
gu
re
1
-
66
Ap
pe
ar
an
ce
of
t
he
AC
P
M m
od
ul
e
Panel
Ta
bl
e
1-
85
I
nd
i
cat
ors
Indicator
Color
Normal
Status
Abnormal
Status
Abnormal
Reason
Input
Green
On
Off
No AC input.
Output
Green
On
Off
The power
module does
not have A
C
output.
Alarm
Red
Off
On
Fans are
faulty
The device
is powered
off due to
overtem
pera
ture.
The device
is powered
off due to
over-output
-
voltage.
The device
is powered
off due to
overcurrent
or short
circuit.
The current
of modul
es
is seriously
imbal
anced.
176
178
