Table 1-231 Mapping products and versions
Earliest Software Version
Appearance
Panel
Table 1-232 Buttons
Before removing a board, press and hold the OFL button
for about 6 seconds until the OFL indicator turns on.
Then, you can remove the board.
Table 1-233 Indicators
Before the board is powered on and registers, this
indicator blinks slowly (2 Hz).
After the board is powered on and registers, if this
indicator blinks at 0.5 Hz, the system is working properly.
If this indicator is steady green, the board is working
properly; if this indicator is off, the board is faulty.
When the board is working properly, the OFL indicator is
off. After the OFL button is pressed to power off the
board, the OFL indicator is on.
Functional Specifications
Table 1-234 Functions and features
To Next Page
