Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
674
Attribute
Description
Model
CR5D00E1NC79
Table 1-1152 Mapping products and versions
Product
Earliest Software Version
NE40E-X3
V800R009C10
NE40E-X8
V800R009C10
NE40E-X16
V800R009C10
NE40E-X3A
V800R009C10
NE40E-X8A
V800R009C10
NE40E-X16A
V800R009C10
Appearance
Panel
Table 1-1153 Buttons
Name
Description
OFL
Board removal button. To remove a board, hold down the OFL
button for about 6s until the OFL indicator turns on, and then remove
the board.
Table 1-1154 Indicators
Name
Description
OFL (red)
If the indicator is steady on, the board can be removed.
RUN (green)
If the indicator blinks once every 2s (0.5 Hz), the system is running
properly. If the indicator blinks twice every second (2 Hz), the board
is starting and has not completed registration.
