16
1. Launch the Internet Explorer on the computer. Enter http://192.168.1.1
in the address bar and press Enter.
2. In the displayed dialog box, enter the user name and the password, and
then click OK.
By default, both the user name and the password are admin. After the password is
verified, you can access the Web configuration page.
Step 2
Enable the embedded dial-up function.
1. In the navigation tree on the left of the configuration page, choose Basic >
WAN Setting.
2. Select a PVC number, such as 1, from the PVC drop-down combo box.
3. In the VPI and VCI text boxes, enter the VPI and VCI values that are
provided by the network operator .
4. Select Yes from the Active drop-down combo box and select Routing
from the Mode drop-down combo box.
5. Enter the operator name, user name, and password in the Login
Information dialog box and keep the default settings of other parameters.
6. Click Submit to save the settings.
After you complete the preceding settings, you can surf the Internet.
You need to perform the preceding operations only once. The next time when you
power on the computer, you can surf the Internet without performing any configuration.
4.2
Accessing the Network Through the PPP
Dial-Up Software on the Computer
If you select this method for accessing the network, you need to install and configure
the dial-up software on the computer. In addition, you need to perform the dial-up
operations on the computer each time after the startup of the computer. To configure the
MT882a and the computer for the network access, do as follows:
Step 1
Set the working mode of the MT882a to
Bridge
.
For details, refer to the procedure for enabling the embedded dial-up function described
in
Step 2 in section 4.1 "Accessing the Network Through the Embedded PPP Dial-Up
Software of the MT882a
." Select Bridge from the Mode drop-down combo box.
Step 2
Install and configure the PPP dial-up software on the computer.
The PPP dial-up software is preinstalled on certain computer operating systems. To
create a dial-up connection, do as follows (taking the Windows XP operating system as
an example):
1. Choose Start > All Programs > Accessories > Communications >
Network Connections.
