● Move the SUN2000 with care to prevent device damage and personal injury.
● When moving the SUN2000, place your hands in the position shown in the
following gure to avoid scratches.
● Place a foam pad or cardboard under the SUN2000 to protect the SUN2000
enclosure from damage.
Figure 4-6 Moving the SUN2000
----End
4.5 Installing the Inverter
Installation Precautions
Figure Mounting bracket dimensions shows the inverter mounting bracket
dimensions.
Figure 4-7 Mounting bracket dimensions
SUN2000-4.95KTL-JPL1
User Manual 4 Installation
Issue 05 (2023-02-17) Copyright © Huawei Technologies Co., Ltd. 30
