Symbol Name Meaning
Grounding Indicates the position for connecting
the protective earthing (PE) cable.
Operation warning Do not remove the DC input
connector when the inverter is
running.
Switching operation
warning
The DC switch may fail to switch o
automatically when it is not
completely closed.
Switch unloaded warning This position indicates that the DC
switch is in unloaded state. Do not
set the DC switch to this position.
Fan operation warning High voltage exists after the inverter
is powered on. Do not touch the
fans when the inverter is working.
Fan replacement warning Before replacing a fan, disconnect its
power connectors.
Inverter ESN label Indicates the inverter serial number.
Weight label The inverter needs to be carried by
four persons or using a pallet truck.
2.4 Product Appearance
SUN2000-(100KTL, 110KTL, 115KTL)-M2
User Manual 2 Overview
Issue 02 (2022-06-30) Copyright © Huawei Technologies Co., Ltd. 11
