4.5 Installing a Solar Inverter
Context
● Move the solar inverter with care to prevent device damage and personal
injury.
● It takes multiple persons or a pallet truck to move the solar inverter.
● Do not use the ports and wiring terminals at the bottom to support any weight
of the solar inverter.
● When you need to temporally place the solar inverter on the ground, use foam,
paper, or other protection material to prevent damage to its cover.
● Use lifting handles to facilitate installation, which are optional and delivered
separately. Ensure that the lifting handles are securely installed. After the
installation is complete, remove the lifting handles and keep them properly.
● To avoid damage to the equipment, do not lift or hoist a solar inverter with an
improper hold as shown in Figure 4-12.
Figure 4-11 Positions for installing the lifting handles
(A) Transportation scenario
(B) Installation scenario
Figure 4-12 Lifting positions
SUN2000-(100KTL, 110KTL, 115KTL)-M2
User Manual 4 Installation
Issue 02 (2022-06-30) Copyright © Huawei Technologies Co., Ltd. 31
