This section will give you a brief overview of some of the components
on the SRC Plus faceplate. Each item will be discussed in further detail
later, however this section can be helpful in getting acquainted with the
different options available.
A – LCD Display
Start Time – Identifies selected start time (only one start time per
program is required).
Program Designator – Identifies program in use A, B, or C.
Station Number – Identifies currently selected station number.
LCD Display – Indicates various times and values.
Run Time – Duration of individual stations watering.
Year – Current calendar year.
Month – Current calendar month.
Day – Current calendar day.
Running – Indicates when watering is occurring.
AM/PM – Arrow differentiates either
AM or PM time.
24 HR – 24-hour time is available in addition to
AM and PM.
Day of the Week – Identifies days of the week to water or you can
select to water on odd or even days.
(For all above LCD display items, when an arrow cursor is flashing,
that is what you are setting.)
B – Control Buttons
Button – Increases the selected flashing display.
Button – Decreases the selected flashing display.
Button – Advances the selected flashing display.
Button – Selects program A, B, or C.
C – Transformer
A 120 VAC Plug-in transformer (included in SRC -600i and 900i models)
supplies 24 VAC to the controller.
D – Control Dial
A key feature of the SRC Plus is its clear, easy-to-use dial design that
makes programming a snap. All essential keypad functions are clearly
marked to eliminate the confusion that’s a characteristic of so many
other controllers.
Run – Normal dial position for automatic and manual operation.
Run (Bypass Sensor) – Used to disengage optional weather sensor
that may be wired to your system.
Set Current Date/Time – Allows current date and clock time to be set.
Set Program Start Times – Allows 1 to 4 start times to be enabled in
each program.
Set Station Run Times – Allows user to set each station run time from
0 to 99 minutes.
Set Days To Water – Allows user to select individual days to water or
to select an odd or even watering schedule, according to the date.
Manual – Single Station – Allows user to activate a one time watering
of a single station.
Manual – All Station – Allows user to activate a one time watering of
all stations or a few selected stations.
System Off – Allows user to discontinue all programs and stop all
watering until dial is returned to the RUN position.
E – Wiring Compartment
Reset Button – This button will reset the controller. All programmed
data will remain intact.
9-Volt Battery – The alkaline battery will maintain the controller
memory if power to the transformer is disconnected. However, the
battery will not operate any of the watering activity (not included).
Transformer – The two wires from the plug-in transformer are
connected to the two AC terminals.
Terminal Strip Area – Use to attach transformer and valve wires from
their source to the controller.
