35
7 Repairs
7.8 Handle, 356BTx
7.8.1 Dismantling the handle
1. Dismount the three screws of the handle.
2. Dismount the spring.
3. Dismount the throttle.
4. Dismount the short-circuit cables.
5. Dismount the throttle cable.
7.8.2 Assembling the handle
1. Mount the throttle cable.
2. Mount the short-circuit cables.
3. Mount the throttle.
4. Mount the spring.
5. Mount the three screws of the handle.
