38 – English
STARTING AND STOPPING
Water safety system
Water is used to prevent overheating the blade while
controlling the dust that results from sawing. The water safety
system monitors the water pressure to the machine and
interrupts the sawing process if the pressure drops.
• Set Speed control lever to the STOP position. The engine
will not start unless the Speed control lever is in the
distinct STOP position.
• When preheat symbol is displayed, wait for the engine
glow plugs to warm the engine. When the preheat symbol
disappears turn the Engine start switch to position engine
start to start the engine.
• Let the engine warm up for several minutes with Engine
throttle at idle speed (minimum).
Start the cutting.
• Test for adequate water supply. Low water flow will cause
damage to diamond blades. Engage the Water safety
switch on the control panel and open the Water valve.
• Engage the Blade clutch (if equipped) to engage the blade
drive. Only at 1200rpm or less.
• Set the Engine throttle knob to maximum rpm.
NOTICE! Check to be certain, the transmission bypass
valve is closed in the down position.
!
CAUTION! Pay special attention on
clutchless machines, blade starts rotating at
start. For safety reason, do not move the
saw sideways or out of the working area with
blade installed and rotating.
NOTICE! If all start conditions are not fulfilled this will be
shown on the display. Perform the action and try to start the
engine again.
1
2
!
WARNING! Never use a blade with a lower
speed rating than that of the machine. Make
sure the blade is properly installed.
NOTICE! See chart for the appropriate blade shaft and
engine speeds for specific blade sizes in the display.
<1200 RPM
1
2
3
4
c
CURRENT: STOP:
00
cm cm
WORKING HOUR
V
8
10
12
16
14
V
100
40
60
80
120
c
8
10
12
16
14
V
100
40
60
80
120
c
<1200 RPM
1
2
3
4
c
CURRENT: STOP:
04
cm cm
WORKING HOUR
V
1200 rpm
<1200 RPM
1
2
3
4
c
CURRENT: STOP:
04
cm cm
WORKING HOUR
V
8
10
12
16
14
V
100
40
60
80
120
c
