48 – English
MAINTENANCE AND SERVICE
• Open the Water valve on the control panel. Make sure it is
straight jets of water out of the holes from the water pipes
on both sides of the blade and no leakage. Replace water
pipe if damaged.
Drain fuel filter water separator from water
• Drain the fuel filter water separator by using the hose in
the bottom. Put the hose in a bottle or a can, loosen the
drain tap and drain any water collected inside the
separator.
After the first 50 hours
Replace engine oil and filter
• Remove the top cap from the hose. Open the valve and
bend it down to empty the system.
Remove the filter and replace it.
Fill the new filter with oil and lubricate the seal with a few
drops of oil prior to refitting it.
FS5000 D
FS7000 D
• Refill the system at either of 2 locations on the engine.
FS5000 D
NOTICE! Treat this water as fuel and dispose properly.
NOTICE! Protect the battery from oil spill prior to removing
and refitting.
1
2
1
2
