ELECTRICAL SYSTEM 15
107
Info
Even when there is no load on the 12-V battery, it discharges steadily each day.
The charging level and the method of charging are very important for the service life of the 12-V battery.
Rapid recharging with a high charging current shortens the service life of the battery.
If the charging current or charging voltage are exceeded, the 12-V battery will be destroyed.
If the 12-V battery is depleted by repeated starting, the 12-V battery must be charged immediately.
If the 12-V battery is left in a discharged state for an extended period, it will become deeply discharged
and suffer a loss of capacity, destroying the battery.
The 12-V battery is maintenance-free.
Preparatory work
– Remove the air filter box cover. ( p. 68)
– Remove the seat. ( p. 67)
– Remove the 12-V battery. ( p. 103)
H03743-10
Main work
– Check the battery voltage.
» Battery voltage: < 9 V
– Do not charge the 12-V battery.
– Replace the 12-V battery and dispose of the old 12-V
battery properly.
» If the specifications have been met:
Battery voltage: ≥ 9 V
– Charge the 12-V battery.
Guideline
Maximum charging volt-
age
14.4 V
Maximum charging cur-
rent
3.0 A
Maximum charging time 24 h
Recharge the 12-V bat-
tery regularly when the
motorcycle is not being
used
6 months
Battery charger (A54029974000)
This battery charger tests whether the 12-V battery
retains its voltage. It is also impossible to overcharge
the 12-V battery with this battery charger. The charg-
ing time may be longer at low temperatures.
This battery charger is only suitable for lithium iron
phosphate batteries. Observe the accompanying fit-
ting instructions for Husqvarna Motorcycles technical
accessories.
Info
Never remove cover
1
.
– Switch off the battery charger after charging and disconnect
from the 12-V battery.
Finishing work
– Install the 12-V battery. ( p. 105)
– Mount the seat. ( p. 67)
