VIEW OF VEHICLE 4
13
4.2 View of vehicle, rear right (example)
S05314-10
1
2-stroke oil tank cap
2
Stop button ( p. 16) (All EU/AR/CN standard models)
2
Stop button ( p. 17) (All US standard models)
2
Horn button ( p. 17) (All EU/AR standard models)
2
Light switch ( p. 17) (All EU/AR/CN standard models)
2
Turn signal switch ( p. 18) (All EU/AR standard models)
3
Emergency OFF switch ( p. 18) (All EU/AR/CN standard models)
3
Start button ( p. 18) (All US standard models)
3
Start button ( p. 18) (All EU/AR/CN standard models)
3
Map switch ( p. 19)
4
Throttle grip ( p. 16)
5
Hand brake lever ( p. 16)
6
Foot brake lever ( p. 23)

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
