31 - ENG
Transportation
To prevent fuel spillage when transporting or during temporary storage, the
generating set should be secured upright in its normal operating position, with the
engine switch "OFF". The fuel valve lever should be turned "OFF".
When transporting:
DO NOT overfill the tank.
DO NOT operate the generator while it is on vehicle. Take the generator off the
vehicle and use it in a well-ventilated place. Avoid a place exposed to direct
sunlight when putting the generator on a vehicle. If the generator is left in an
enclosed vehicle for many hours, high temperature inside the vehicle could cause
fuel to vaporize resulting in a possible explosion.
DO NOT drive on a rough road for an extended period with the generator on
board. If you must transport the generator on a rough road, drain the fuel from the
generatorbeforehand
SPECIFICATIONS
Specification Parameter Table
Model
HPGH550 HPGH8500 / HPGH8500E
Engine
parameter
Engine model GX270 GX390
Displacement (cm
3
) 270 389
Start style Recoil
(electric start optional)
HPGH8500 = Recoil /
HPGH8500E = Recoil & Electric Start
Oil capacity (L) 1.1 1.1
Generator
parameter
Frequency (Hz) 60 60
Voltage (V) 120 (120/240) 120 (120/240)
Phase Single Single
Rated running power (kW) 4.5 7.0
Rated starting power (kW) 5.5 8.5
Power factor 1.0 1.0
Insulation rate F F
Fuel capacity (L) 30 30
