To make a three point turn to the right:
1. Move the left steering control lever farther forward
from neutral than the right steering control lever and
start the turn. Figure 3-9
2. Next, pull back on the steering control levers until they
pass neutral and the machine starts to go rearward.
Figure 3-9
3. Pull the right steering control lever farther rearward
from neutral than the left steering control lever until
the rear of the machine pivots around. Figure 3-9
4. Then, push the steering control levers forward until
they both pass neutral and the machine starts to go
forward. Figure 3-9
5. Push the left steering control lever farther forward
from neutral than the right steering control lever and
finish the turn. Figure 3-9
IMPORTANT: Damage to the hydraulic system compo-
nents may occur with rapid movement of the steering con-
trols.
To increase speed, increase the steering control lever’s
distance from neutral. The farther forward the steering
control levers are from neutral, the faster the mower will
travel forward. The farther back the steering control levers
are from neutral, the faster the mower will go in reverse.
Always be aware of what is behind the machine
before backing up. Do not mow in reverse unless
absolutely necessary. Always look down and
behind before and while backing up.
WARNING
Figure 3-8
FORWARD TRAVEL
FRONT OF MOWER FACES THIS DIRECTION
ZERO RADIUS TURN
FORWARD TRAVEL
RIGHT TURN
REVERSE TRAVEL
RIGHT TURN
REVERSE TRAVEL
N = NEUTRAL POSITION
Direction of arrows indicate direction of mower
movement
N
N
N
N
N
N
N
N
N
N
