Fuel and Evaporative Emissions Control System
IMPORTANT: Refer to the Safety section of this manual for
fuel handling safety information.
Use only Hustler
®
approved replacement parts.
Your evaporative emission control system may include
parts such as:
• fuel tanks
• fuel lines
• fuel line fittings
• fuel caps
• carbon canisters
• canister mounting brackets
• carburetor purge port connection
• filters
• vapor hoses
• clamps, control valves
• control solenoids
• electronic controls
• vacuum control diaphragms
• purge valves
• liquid/vapor separator
• other associated components
The fuel tank is located to the left of the operator platform.
Park the mower on level ground before filling the fuel tank.
Clean the area around the fuel cap before removing the
cap. Remove the fuel cap slowly.
When threading the fuel cap onto the filler neck, tighten the
cap until it begins to click, then, continue to turn it until at
least three clicks are heard.
A. Sight glass
Figure 4-3
A. Hydraulic reservoir
Figure 4-4
A
A
A. Hydraulic filter
Figure 4-5
Use of replacement parts not equivalent to the
original parts may result in system failure and
pose a safety hazard.
A
WARNING
To Next Page
