Élément Numéro de pièce Qté Nom
1 1 REFER TO "HANDLEBAR - STEERING SUB-ASSMBLY"
2 606980 1 KNOB, POLYPROPYLENE
3 110645 1 NEUTRAL LOCK HANDLE ROD
4 047456 1 GM .750X.188X1.00X.12
5 045765 3 FW 1.030X1.50X.13 HD ZN
6 784223 2 BEARING
7 768523 10 FW 0.343SAE
8 041152 2 NT 0.312-24 HX G8
9 550192 1 CONSOLE TS SERV ASSY
10 605669 1 DECAL, TrimStar ID
11 601935 1 DECAL, TS INST PNL ES
12 771030 1 DECAL, H-BAR STEERING
13 601967 1 DECAL, ENGINE COMPART
14 767962 2 FW .531 x 1.063 x .175
15 073338 1 CE .500X4.50 .156X4.34
16 017251 1 CP .156DX1.000 LG HML Z
17 054502 10 NT .375-16HXG5
18 768259 6 BUSHING,IGUS#0810 (FS)
19 119748 1 NEUTRAL LOCK YOKE ASSY
20 604448 1 UHMW CHANNEL
21 076422 1 FW 0.406X1.00X.06 ZN
22 086660 1 NT .375-16NLG8
23 305086 1 PIVOT PIN
24 110639 2 BELLCRANK W/A
25 601953 1 WASHER, WAVY .558x1.005
26 788554 1 LOCK COLLAR, .500x1.000
27 058776 3 NT .312-18NLG5
28 601952 2 PUMP ADJUSTMENT ROD
29 601098 6 CB 10-24 X .500 ZYNC
30 016832 2 NT .312-18FLKG5
31 034652 1 SPRING 2.5
32 785113 1 CS .312-18X4.250 HX G5
33 055863 2 NT #6-32 HX G5 NL ZN
34 023002 1 DOUBLE POLE SWITCH
35 110646 1 NEUTRAL SWITCH BRKT
36 704932 4 FW 0.219X.50X.05 ZN
Instrument Panel (Multi-Page)
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:22 UTC 2020 4-3
