Comments for Page: Deck Pulleys & Spindles

1. Torque to 99 N•m.

2. Torque to 41 N•m.

3. Torque to 4–8 N•m.

Élément Numéro de pièce Qté Nom

1 781567 3 NT .500-13NLG5

2 125847-4 1 BELT GUIDE, 4.00" IDLER

3 607428 1 FW 0.531 X 0.90 X 0.134

4 605467 3 DUST SHIELD

5 605512 1 4" IDLER PULLEY

6 121052 1 SLED, TENSIONER

7 607616 1 SPRING, DECK IDLER

8 604251 7 NT .312-18 HXNL JAM G2ZN

9 604252 6 FW .340X.68X.04 ZN

10 604790 2 IDLER SLIDE, EXTRUDED

11 604253 1 CB .50-13 X 2.00 STD ZN

12 705954 3 CS .500-13X1.25 HX G5 ZN

13 798603 3 FW .515X1.65X.12 HD ZN

14 607505 3 PULLEY, B-SEC 4.784" EOD

15 606362 3 DUST SHIELD

16 604515 12 NT .375-16 FL NY GF

17 604486 2 FW .531X.812X.089 HD

18 607479 2 IDLER PULLEY, 5.00"

19 605465 1 BASE, IDLER PULLEY MOUNT

20 017129 1 FW .440X1.00X0.08 ZN

21 605508 1 FW .73X2.25X.31 ZN

22 607208 3 BLADE SPINDLE ASSY

23 016253 7 CB .312-18X .750 FUL ZN

24 604254 2 CB .50-13 X 2.50 STD ZN

Deck Pulleys & Spindles

48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC

Thu May 28 06:43:32 UTC 2020 7-2
