Élément Numéro de pièce Qté Nom
1 1 ENGINE, KAW FS600V
2 603187 1 MUFFLER, FS600V TRIMSTAR
3 016253 5 CB .312-18X .750 FUL ZN
4 016832 7 NT .312-18FLKG5
5 124363-1 1 MUFFLER MOUNT
6 720516 3 CS M8-1.25X16HX FL10.9
7 113970 1 CABLE GUIDE
8 000398 1 CLAMP - 50 CNT BAGS
9 768523 7 FW 0.343SAE
10 036236 4 CS .312-18X1.000HXG5
11 604463 1 HOSE, OIL DRAIN
12 767954 4 FW 0.379X.82X.06 HD ZN
13 602580 4 CS .375-16X1.25HXG8ZYP85
14 603524 1 CS M5-0.8 X 50 MM
15 124466-1 1 CLUTCH ANCHOR
16 712372 1 KEY 1/4 SQ X 0.66 LG(FS)
17 000331 3 WIRE TIE, SMALL/SHORT
18 791251 1 HARNESS, CLUTCH PIGTAIL
Commentaires pour le numéro de pièce 791251
Pigtail was updated with epoxy to hold the wires steady. The wire sheath was also updated to a more flexible material.
19 607494 1 PULLEY - ENGINE
20 607495K 1 KIT - CLUTCH
21 602680 1 FW .453X1.12X.12 HRD ZN
22 785048 1 CS .437-20X3.00 HXG5 P85
23 000323 2 CLIP, HOSE CLAMP
24 015818 12.5" FUEL LINE, 1/4"
Commentaires pour le numéro de pièce 015818
Sold by the foot.
25 603112 2 CLAMP, 3/16 FUEL
26 603326 34" VAPOR LINE, 3/16"
Commentaires pour le numéro de pièce 603326
Sold by the foot.
27 043570 2 CLIP - HOSE - SINGLE(FS)
Engine, Muffler & Clutch (Multi-Page)
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:28 UTC 2020 6-1
