HUSTLER TrimStar Parts Manual
4
of 1
of 1 rating
60 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Élément
Numéro de pièce
Qté
Nom
1
125825-1
1
FORK W/A
2
781567
1
NT .500-13NLG5
3
767962
2
FW .531 x 1.063 x .175
4
042630
1
CS .500-13X6.500HXG5
5
306969
1
GAGE WHEEL SPACER
6
606740
1
TIR/WHL 11X4.00-5 SLV
7
606779
2
DUST CAP, 0.502 ID
8
606780
2
SEAL
9
606778
2
SPACER, 0.531
10
606753
2
BEARING, TAPERED ROLLER
Front Wheel Assembly
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:26 UTC 2020
5-2
34
36
Table of Contents
Table of Contents
3
General Information
4
Frame & Cover
6
Frame
7
Cover
9
Transmissions, Drive Belt, Handlebar, Instrument Panel & Brake
10
Transmissions, Hoses & Drive Belt (Multi-Page)
11
Transmission Service Parts
19
Instrument Panel (Multi-Page)
21
Handlebar - Steering Sub-Assembly
29
Brake
30
Wheels & Tires Wheels & Tires
32
Front Wheel Assembly
35
Drive Wheel Breakdown
37
Engine, Muffler, Clutch & Fuel System
38
Engine, Muffler & Clutch (Multi-Page)
39
Engine Service Parts
43
Battery
44
Fuel System
46
Fuel Tank Service Parts
49
Deck, Deck Belt, Blades & Deck Lift
50
Service Deck
51
Deck Pulleys & Spindles
53
Spindle Service Parts - 607208
55
Deck, Deck Belt & Blades
57
Deck Lift & Mounting Hardware (Multi-Page)
59
