SPECIFICATIONS
2-4 powermax380 Operator Manual
0
O
l
Direct Current (DC)
The terminal for the external
protective (earth) conductor
AC input power connection
Plasma torch cutting
Alternating current (AC)
A chopper-based power source
Power is OFF
Power is ON
Plasma torch in the TEST
position (cooling and cutting
gas exiting nozzle)
Symbols and Markings
S
Mark
The S mark indicates that the power supply and torch are suitable for use in environments with increased hazard
of electrical shock.
IEC Symbols Used
The following symbols may appear on the power supply data plate, control labels and switches.
ACAC
ON
Alternating current (AC)
Inlet gas pressure
Consumables are
loose or missing
Power supply is over heated
Light ON
Light OFF
Light blinking

Hypertherm powermax 380 Specifications

General

Brand	Hypertherm
Model	powermax 380
Category	Welding System
Language	English
