5-8 powermax380 Operator Manual
0
MAINTENANCE AND PARTS
Parts
PAC110T Hand Torch Assembly
Item Part Number Description Quantity
070071* PAC110T Hand Torch Assembly with 20 ft (6.1 m) Lead
1 001288 Handle, 2 Sides 1
2 002244 Safety Trigger 1
3 128377 Replacement Start Switch (switch and wire splices) 1
4 027254 Trigger Spring 1
5 004764 Gutcha Retaining Ring 1
6 075339 Screws, P/S, # 4 X 1/2, PH, RND, S/B 5
7 120976 Torch Main Body with Safety Switch 1
8 058503 O-Ring: Viton .625 X .070 1
9 128554 Replacement 20 ft (6.1 m) Torch Lead 1
* Top assembly includes the following consumables (See page 4-3 for details of consumable parts):
020382 Electrode 1
220013 Swirl Ring 1
220016 Retaining Cap 1
120504 Nozzle 1
